Alpine HD+

Ultimate heavy duty for extreme conditions.
Uv up to 0.166 Btu/h⋅ft²⋅°F
Datasheet

Perfomance

U-value0.166 Btu/h⋅ft²⋅°F
ASTM E283CW classAir Leakage
ASTM E547720paWater Penetration
ASTM E330DP100Load Structural
ASTM F588-17Grade 10Entry Resistance
Profile width2 mm
Frame width89.8 mm
Frame height68 mm
Purpose
Most load effective


Opening

French style tilt and turn. One sash — turn, another sash — tilt and turn.

Tilt and turn operable window inside opening.

Fixed window with tilt and turn vent inside opening.

Triple sash operable window. Side sashes — tilt and turn, middle sash — turn.

Tilt operable window inside opening.

Fixed view window any shape and size.

Finishes

Anodized, RAL

Powder coating, RAL

Artificial wood pallete

Artificial stone pallete

Hardware

  • Eurogroove, adaptable to all hardware
  • Option for concealed hinges
  • Painted handles
  • Top global hardware manufacturers
